Baja Designs 701003 S8 Straight LED Light Bar
$350
Made to order
Universal fit — no vehicle-specific fitment required.
Qty
1
Free freight ≥ $999 · $40 flat below
About this part
The S8 LED light bar from Baja Designs offers a slim and sleek design utilizing eight LEDs per 10-inch section. Lumens start at 6 324 raw lumens per 10" section the S8 is available from 10" to 50" and features high-performance reflectors along with the additional feature of an amber backlight making the S8 a light bar that shines with your vehicle. The S8 LED light bar is backed by our 30-day Satisfaction Guarantee and Limited Lifetime Warranty giving you the ultimate in-purchase protection! NOTE:This light does NOT include a harness. The applicable harnesses are 640122 (On/Off with mode switch for backlight) or 640115 (On/Off 3-pin for one light 10"-30").
Specifications
| WIDTH | 5.000 |
|---|---|
| HEIGHT | 7.000 |
| LENGTH | 16.000 |
| PROP65 | Yes |
| WEIGHT | 5.000 |
| WARRANTY | Limited Lifetime |
| EMISSIONS | Emissions Compliance Exempt |
| ATTRIBUTES | Add-On:Accessories-708201-Rock Guard (Black);Add-On:Accessories-708202-Light Cover (Amber);Add-On:Accessories-708203-Light Cover (Clear);Add-On:Accessories-708301-Lens Kit (Spot; Clear);Add-On:Accessories-708303-Lens Kit (Driving/Combo; Clear);Add-On:Accessories-708304-Lens Kit (Wide Cornering; Clear);Add-On:Accessories-708313-Lens Kit (Driving/Combo; Amber);Add-On:Accessories-708314-Lens Kit (Wide Cornering; Amber);Add-On:Compatible Products-613608-Harness Splitter;Add-On:Compatible Products-613609-Harness/Splitter (55 Inch);Add-On:Compatible Products-640094-Upfitter Harness;Add-On:Compatible Products-640115-Wiring Harness (On/Off);Add-On:Compatible Products-640122-Wiring Harness (Mode Switch);Add-On:Compatible Products-640163-Harness/Splitter (Hi Beam);Add-On:Compatible Products-640177-Backlit Add-On;Add-On:Associated Products-660302-Anti Theft Hardware Kit - 1/4-20x1/2 Socket Pin Head Bolts;Add-On:Associated Products-660303-Anti Theft Hardware Kit - 3/8 in. Tamperproof Nuts;Amperage Rating (A):4.200 Specifications;Average Rated Life (hr.):49 930 Specifications;Beam Pattern:Driving/Combo Specifications;Bezel Material:Billet Machined Aluminum Specifications;Brightness (Lumens):6324 Specifications;Depth (in.):3 Dimensions;DES:S8 Straight LED Light Bar;Description:Driving/Combo; Clear Specifications;EXT:S8 Straight LED Light Bar (10 Inch; Driving/Combo; Clear);Height (in.):1.600 Dimensions;Housing Color:Black Specifications;Housing Material:Aircraft Grade Aluminum with Mil-Spec Hard Anodize Specifications;Length (in.):10 Dimensions;Lens Color:Clear Specifications;Lens Material:Hardcoated Polycarbonate Specifications;Light Quantity:1 Specifications;Lighting Modes:Beam/Amber Backlit Feature Specifications;Lighting Quantity:8 Specifications;Lighting Technology:Cree LED Specifications;Lighting Type:Forward Projecting Specifications;Mounting Hardware Description:Mounting Brackets Specifications;Mounting Hardware Included:Yes Specifications;Mounting Hardware Material:Stainless Steel Specifications;Overvoltage Protection:Built-In Specifications;Patent No.:D780 964 Standards & Complian;Product Type:S8 10 Inch LED Light Bar Specifications;Prop 65 - Short Label:CR;Prop 65 Warning Label:Prop 65 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.;Prop 65 Yes/No:Yes;Standards/Compliance (Durability):Exceeds MIL-STD810G (Mil-Spec Testing) Standards & Complian;Standards/Compliance (Impact Resistance):IK10 Compliant (Mechanical Impact Testing) Standards & Complian;Standards/Compliance (Water Resistance):IP69K (Waterproof up to 9ft & Pressure Washable) Standards & Complian;TLE:S8 Straight LED Light Bar (10 Inch; Driving/Combo; Clear);Universal or Specific:Universal Specifications;Wattage (W):57.960 Specifications;Weight (lbs.):2.400 Dimensions;Wiring Harness Included:No Specifications |
| PCDB CATEGORY | Electrical Lighting and Body |
| COUNTRY OF ORIGIN | US |
| PART TERMINOLOGY | Light Bar |
| VEHICLE SPECIFIC FITMENT | N |
| INSTALLATION INSTRUCTIONS |
Datasheet — not yet published
