suspension and steering
Bilstein 35-212799 Universal Motorsports Strut - Suspension Strut Assembly
$549
Made to order
Universal fit — no vehicle-specific fitment required.
Free freight ≥ $999 · $40 flat below
About this part
Bilstein Universal Motorsports Struts are massive 46mm I.D. inverted monotube dampers intended to be adapted to MacPherson strut style suspension systems. The strut insert is provided with a blank upper-stem that can be machined down to fit a specific top mount or camber/caster plate variations. Each strut is supplied with a matched external housing that permits the builder to fabricate weld tabs for mounting the unit to a vehicle's lower steering knuckle. Additionally the threaded housing allows the builder to adjust the ride height of the vehicle to ensure the proper ride height is met in order for the vehicle to perform at the highest level possible.
Specifications
| WIDTH | 7.0000 |
|---|---|
| HEIGHT | 2.0000 |
| LENGTH | 37.0000 |
| PROP65 | |
| WEIGHT | 15.0000 |
| WARRANTY | 3 Months |
| EMISSIONS | Emissions Compliance Exempt |
| ATTRIBUTES | Boot Included:No;Collapsed Length (IN):11.89;Collapsed Length (MM):302.0;Extended Length (IN):17.72;Extended Length (MM):450.0;Finish:Olive-Drab Zinc;Internal Design:Monotube;Lower Mount Type:Housing;PartType:Shocks / Struts;Prop 65 (Y/N):Y;Prop 65 - Short Label:WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov;Rebound @0.52m/s:3780;Segment:Motorsports;Series:Universal Motorsports Strut;Shaft Diameter:14mm;Spring Hardware:2.5in;Spring Seat Included:Yes;Stroke/Travel Length (IN):5.83;Stroke/Travel Length (mm):148.1;Title:Bilstein Shock Absorbers;Upper Mount Type:Stem |
| PCDB CATEGORY | Suspension |
| COUNTRY OF ORIGIN | US |
| PART TERMINOLOGY | Suspension Strut Assembly |
| VEHICLE SPECIFIC FITMENT | N |
| INSTALLATION INSTRUCTIONS | https://sdda.semadata.org/Standard/Thyssen Krupp Automotive Group/Generic_instructions_02.pdf |
Datasheet — not yet published
