Edelbrock 61339 Victor Jr Gen III/ IV LS Chevy Cylinder Head Standard Block
$2,306
Made to order
Universal fit — no vehicle-specific fitment required.
Free freight ≥ $999 · $40 flat below
About this part
The Edelbrock #61339 Victor Jr. LS3 cylinder head is ideal for use in high Performance's street and competition engines that have reached their limit with a stock-style cylinder head design. Most aftermarket LS3 cylinder head on the market today are simply stock head designs with larger ports. Our Victor Jr. LS3 cylinder head is an all-new ground up design that incorporates subtle changes for improved flow and combustion. These changes were made to improve the limitations encountered in the stock cylinder head when increasing the performance level of the engine. Changes include a 2.20" diameter intake valve with a canted configuration similar to what is utilized in the GM LT1 Gen V engine. The intake valve change along with the unique port shape produce almost 400cfm peak flow. This cylinder head also feature fully CNC intake ports combustion chambers and exhaust ports for consistency and improved performance. All of these changes make this cylinder head capable of producing 600+ hp on an LS3 engine with stock rocker arms intake manifold and exhaust manifolds.
Specifications
| WIDTH | 10.13 |
|---|---|
| HEIGHT | 7.19 |
| LENGTH | 22.19 |
| PROP65 | |
| WEIGHT | 24.85 |
| WARRANTY | 12 Months |
| EMISSIONS | CARB Eligible |
| ATTRIBUTES | Material:Aluminum;Exhaust Runner Volume:85 CCM;Grade Type:Performance;Deck Thickness:0.625 IN;Combustion Chamber Volume:69 CCM;Intake Runner Volume:280 CCM;Intake Valve Diameter:2.20 IN;Exhaust Valve Diameter:1.60 IN;Valve Spring Diameter:1.30 IN;Valve Spring Maximum Lift:0.680 IN;Guide Plates Included:No;Head Casting Number:N/A;Valve Springs Included:Yes;9040:D-215-98;Camshaft Type:Hydraulic Roller;CNC Ported:No;Construction Type:Complete;EGR Port:No;Exhaust Port Location:+.125;Guide Material:Manganese Bronze;Horsepower:500-650 HJ;Product Family:Victor;Product Series:Victor Jr.;Quantity:Sold Individually;Retainer Included:Yes;RGL:WARNING: This product can expose you to Lead which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information visit www.P65warnings.ca.gov.;Seat Angle:Exhaust 39 deg/Intake 37 DD;Seat Material:Ductile Iron;Valve Angle:Exhaust 11 X 0 deg/Intake 11 x 3 DD;Valve Included:Yes;Valve Stem Diameter:0.314961 IN |
| PCDB CATEGORY | Engine |
| COUNTRY OF ORIGIN | US |
| PART TERMINOLOGY | Engine Cylinder Head |
| VEHICLE SPECIFIC FITMENT | N |
| INSTALLATION INSTRUCTIONS | 61339.pdf |
Datasheet — not yet published
