Haltech HT-193000 Nexus R3 - VCU
$2,399
Made to order
Universal fit — no vehicle-specific fitment required.
Qty
1
Free freight ≥ $999 · $40 flat below
About this part
Nexus R3 - VCU
Specifications
| WIDTH | 8.75 |
|---|---|
| HEIGHT | 2.25 |
| LENGTH | 9.25 |
| PROP65 | Yes |
| WEIGHT | 3.7191 |
| WARRANTY | |
| EMISSIONS | |
| ATTRIBUTES | 25A High Current Outputs (HCO):4;Analog Voltage Inputs (AVI):11;Anti-Lag/Rotational Idle:YES;Boost Control:4D Closed Loop;CAN Bus Networks:2;Closed Loop O2 Control:Dual;CO2 Control:YES;Compatible with Haltech Connect App:YES;Differential Engine Position Inputs:2 (Trigger and Home);Digital Pulsed Inputs (DPI):0;Display Name:Nexus R3 - VCU;Drive-By-Wire Throttle:Dual;Engine Control Relay output:0;Engine Protection:Multi-Level;Flat Shift Support:Advanced;Flex Fuel:YES;Half Bridge Outputs (HBO):6 8A;Ignition:8;Ignition Switch Input:1;Inertia / G-Sensor:YES;Injection:8 (peak and hold);Intake Air Bleed Control:YES;Knock Control:Dual;Knock Sensor Inputs:2;Launch Control:YES;Long Term Learning:Up to 4D;Low Power Up via Cable:YES;MAP sensor:Internal (4 BAR);Nitrous Control Stages:Up to 6;On-Board PDM:YES;On-board Wideband Controller:1 x NTK/LSU 4.9;Onboard storage:128MB;Product Type:ECU;Prop 65 (C R or CR):CR;Prop 65 - Short Label:Prop 65 Warning Label.JPG;Prop 65 Yes/No:Yes;Race Timer:YES;Rolling Anti-Lag:YES;Shock Travel & Ride Height:YES;Synchronized Pulsed Inputs (SPI):6;Title:Haltech Nexus R3 - VCU - HT-193000;Torque Management (Driveshaft and Engine RPM Targeting):YES;Total Digital Pulsed Outputs (DPO):6;Traction Control:YES;Trans Brake:YES;Tuning Table Resolution:32x32x8 4D;USB 2.0:USB-C;Variable Cam Control:Up to 4;Wi-Fi:YES |
| PCDB CATEGORY | Electrical Lighting and Body |
| COUNTRY OF ORIGIN | AU |
| PART TERMINOLOGY | Vehicle Control Module |
| VEHICLE SPECIFIC FITMENT | N |
| INSTALLATION INSTRUCTIONS |
Datasheet — not yet published
