Mishimoto MMINT-TAC-24KSLBK Intercooler Kit, Silver/Black, fits Toyota Tacoma 2024+
$1,240
Made to order
Add your car with the “Your car” button in the header to check fitment.
Free freight ≥ $999 · $40 flat below
About this part
The 2024+ Tacoma's T24A-FTS builds heat soak under repeated load - the factory tube-and-fin intercooler loses cooling capacity across consecutive WOT runs towing grades and sustained trail use. The Mishimoto Intercooler and Charge Pipe Kit addresses the full charge air system in one purchase: a 55% larger bar-and-plate core paired with aluminum charge piping DuraCore™ couplers and constant-tension clamps matched from intercooler to throttle body.--The bar-and-plate core cuts intake air temps by up to 36°F at wide-open throttle and delivers 30% lower pressure drop than stock reducing turbocharger strain and maintaining boost efficiency under load. An included custom shroud directs full airflow to every row of the oversized core - no trimming required. Cast end tanks billet aluminum ORB ports updated mounting bushings and an included crush washer complete the hardware package for a sealed long-term install.--The system preserves Toyota's adaptive cruise control with no sensor relocation. Fits the 2024+ Toyota Tacoma (T24A-FTS N400) and 2024+ Toyota Land Cruiser LC250. Available in Silver or Stealth Black intercooler finish with matching Wrinkle Black or Wrinkle Red charge pipes. Compatible with OEM and Mishimoto components for future cooling system expansion. Backed by the Mishimoto Lifetime Warranty.
Specifications
| WIDTH | 18.81 |
|---|---|
| HEIGHT | 18.81 |
| LENGTH | 18.81 |
| PROP65 | Y |
| WEIGHT | 37 |
| WARRANTY | Lifetime Warranty |
| EMISSIONS | EPA Eligible |
| ATTRIBUTES | End Tank Material:Aluminum;Pipe Finish:Powder Coated;Hot Side Pipe Inside Diameter:2.03 IN;Cold Side Pipe Inside Diameter:2.22 IN;Intercooler Type:Air-to-Air;Core Construction:Bar-and-Plate;End Tank Construction:Cast;Core Height:8.87 IN;Core Thickness:3.5 IN;Core Material:Aluminum;Universal Or Specific Fit:Specific;Grade Type:Performance;Pipe Material:Aluminum;Pipe Color:Black;Core Length:24.13 IN;Inlet Diameter:2.03 IN;Coupler Color:Black;Coupler Material:Silicone;Hose Clamps Included:Yes;Outlet Diameter:2.22 IN;Maximum Boost Pressure:50 PS;Core Color:Silver;Maximum Horsepower:650 HJ;Install Difficulty:4;OptionLabel:Silver Intercooler Black Pipes;Prop 65 - Short Label:WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov;Prop 65 Y/N:Y;SellingPoint01:Cuts charge air temps by up to 36°F at wide-open throttle — a 55% larger bar-and-plate core provides the heat-sink capacity the factory tube-and-fin unit loses under repeated WOT pulls towing grades and sustained off-road operation.;SellingPoint02:Reduces turbocharger stress with 30% lower pressure drop than OEM — optimized airflow through the 3.50-in thick core maintains boost pressure and consistent power across the RPM range under sustained demand.;SellingPoint03:Included custom shroud ensures full airflow reaches every row of the oversized core — no trimming no gaps and no performance loss from an undirected core face that would otherwise undercut the 55% volume increase.;SellingPoint04:Complete kit includes aluminum charge pipes DuraCore™ silicone couplers and constant-tension clamps — everything for a full intercooler system upgrade in a single purchase with matched Wrinkle Black or Wrinkle Red pipe finishes.;SellingPoint05:Cast end tanks and billet aluminum ORB ports replace the factory unit's construction — updated mounting bushings and an included crush washer ensure a sealed rattle-free install matched to OEM mounting points.;SellingPoint06:Drops in with zero sensor relocation and full Toyota adaptive cruise control function preserved — confirmed direct fit for the 2024+ Toyota Tacoma (T24A-FTS N400) and 2024+ Toyota Land Cruiser LC250.;SellingPoint07:Engineered as a matched system from intercooler core to throttle body — all components are sized and tested together eliminating the flow mismatches and sealing inconsistencies that result from pairing parts across different brands or separate kits.;SellingPoint08:Own it for life — backed by Mishimoto's Lifetime Warranty your investment is protected long after install day.;SellingPoint09:N/A;SellingPoint10:N/A;SellingPoint11:N/A;SellingPoint12:N/A;SellingPoint13:N/A;SellingPoint14:N/A;SellingPoint15:N/A;TechSpec Applications:Toyota Tacoma 2.4L L4 2024+--Toyota Land Cruiser 2.4L L4 2024+;TechSpec Centerline Radius:N/A;TechSpec Chassis Codes:N400;TechSpec Core Height (in):8.87;TechSpec Core Length (in):24.13;TechSpec Core Thickness (in):3.5;TechSpec Core Type:Bar-And-Plate;TechSpec Engine Codes:T24A-FTS;TechSpec Includes:(1) Performance Intercooler--(2) Vacuum Fittings--(1) Intercooler Duct--(1) Intercooler Duct Bracket--(2) Hot-Side Intercooler Pipes--(2) Cold-Side Intercooler Pipes--(2) Silicone Couplers--(1) Bill Of Materials Notecard--Mishimoto Lifetime Warranty;TechSpec Inlet (in):2.03;TechSpec Installation Notes:N/A;TechSpec Maximum Recommended Boost Pressure (PSI):50;TechSpec Maximum Recommended Horsepower:650;TechSpec Note:2024+ Toyota Land Cruiser (LC250) installation may require removal of a bracket on the top of the AC condenser.;TechSpec Outlet (in):2.22;TechSpec Overall Height (in):N/A;TechSpec Overall Length (in):N/A;TechSpec Overall Width (in):N/A;TechSpec Pipe Diameter:2.5" (Hot-Side) 3" (Cold-Side);TechSpec Pipe Length:N/A;TechSpec Pipe Shape:N/A;TechSpec Weight (lbs):N/A |
| PCDB CATEGORY | Belts and Cooling |
| COUNTRY OF ORIGIN | CN |
| PART TERMINOLOGY | Intercooler Kit |
| VEHICLE SPECIFIC FITMENT | Y |
| INSTALLATION INSTRUCTIONS | https://sdda.semadata.org/Standard/Mishimoto Automotive/MMINT-TAC-24_Install-Guide.pdf |
| VERIFIED FITMENT |
|
