Mishimoto MMTC-F150-04 Transmission Cooler, Silver, fits Ford F-150 2004-2008
$350
Made to order
Add your car with the “Your car” button in the header to check fitment.
Free freight ≥ $999 · $40 flat below
About this part
The factory transmission cooling on the 2004-2008 Ford F-150 is sized for stock duty and fluid temperatures climb fast under the sustained load of towing and hauling. Heat is what wears a transmission out. The Mishimoto Transmission Cooler attacks the problem with raw capacity: a tube-and-fin core with a 174% increase in core volume over the factory Standard Cooling setup giving the system far more headroom to keep fluid temperatures in a safe range when the truck is working hardest.----It doesn't just beat the base cooler - with a 32% increase in core volume over the F-150 Super Cooling option it runs cooler than the heaviest-duty cooling Ford offered from the factory. A 286% increase in external fin area and 305% increase in internal fin area move heat from the fluid into the airstream far more efficiently and all-aluminum construction handles the thermal demands of stock and modified F-150 trucks alike. The cooler retains the factory transmission line connections and includes new fittings plus a fitting removal tool for a clean complete upgrade with no additional adapters or plumbing.----Direct fit for the 2004-2008 Ford F-150 4.6L and 5.4L V8. No drilling cutting or modification required. Backed by the Mishimoto Lifetime Warranty.
Specifications
| WIDTH | 6.6 |
|---|---|
| HEIGHT | 9.6 |
| LENGTH | 24.2 |
| PROP65 | Y |
| WEIGHT | 8 |
| WARRANTY | Lifetime Warranty |
| EMISSIONS | Emissions Compliance Exempt |
| ATTRIBUTES | Line Included:No;Thickness:1.81 IN;Finish:Natural Aluminum;Width:22.52 IN;Core Height:7.91 IN;Core Thickness:1.26 IN;Core Width:18.9 IN;Mounting Hardware Included:Yes;Core Material:Aluminum;Height:8.07 IN;Grade Type:Performance;Electric Fan:No;Inlet Diameter:0.375 IN;Outlet Diameter:0.375 IN;Cooler Fluid Capacity:0.9 QT;Install Difficulty:2;Prop 65 - Short Label:WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov;Prop 65 Y/N:Y;SellingPoint01:174% more core volume for serious heat dissipation - the oversized tube-and-fin core pulls far more heat from the fluid than the factory Standard Cooling setup under tow and heavy load.;SellingPoint02:Outcools even the factory tow package - a 32% increase in core volume over the F-150 Super Cooling option means it runs cooler than the heaviest-duty cooling Ford offered.;SellingPoint03:New fittings and removal tool included - bolts to the factory transmission line connections and ships with new fittings and the removal tool so no extra parts or tools are needed.;SellingPoint04:Tube-and-fin aluminum core built for sustained load - durable all-aluminum construction holds transmission temperatures in check through the heat of towing where the stock cooler falls short.;SellingPoint05:286% more external and 305% more internal fin area - the added fin surface moves heat from the fluid into the airstream far faster than the factory Standard Cooling core.;SellingPoint06:Drops in without modification - confirmed direct fit for 2004-2008 Ford F-150 4.6L and 5.4L V8 trucks with no cutting fabricating or adapter work required.;SellingPoint07:Own it for life - backed by Mishimoto’s Lifetime Warranty your investment is protected long after install day.;TechSpec Chassis Codes:P221;TechSpec Core Construction:Tube-And-Fin;TechSpec Core Height (in):7.91 IN;TechSpec Core Length (in):18.9 IN;TechSpec Core Thickness (in):1.26 IN;TechSpec Engine Codes:4.6L Triton V8--5.4L Triton V8;TechSpec Includes:(1) Mishimoto Transmission Cooler--(1) Mounting Bracket & Hardware Kit--(1) Line Removal Tool;TechSpec Inlet:0.375 IN;TechSpec Outlet:0.375 IN;TechSpec Overall Height (in):8.07 IN;TechSpec Overall Length (in):22.52 IN;TechSpec Overall Width (in):1.81 IN;TechSpec Rows:19;TechSpec Transmission Codes:4R70E--4R75E |
| PCDB CATEGORY | Belts and Cooling |
| COUNTRY OF ORIGIN | CN |
| PART TERMINOLOGY | Automatic Transmission Oil Cooler |
| VEHICLE SPECIFIC FITMENT | Y |
| INSTALLATION INSTRUCTIONS | https://sdda.semadata.org/Standard/Mishimoto Automotive/MMTC-F150-04_Install-Guide.pdf |
